A door closer can be installed with every screw perfectly tight and still perform badly. The reason is simple: a closer is not just a box attached to the top of a door. Its performance depends on the relationship between the door width, door weight, closer spring power, mounting geometry, arm position, hinges or pivots, frame, latch, opening angle, and hydraulic adjustments. That is why professional swing door closer installation begins before drilling the first mounting hole.
LCN describes the closer’s job as controlling both the opening and closing cycles. During opening, backcheck can cushion excessive movement near the end of the swing; during closing, the closer controls the main sweep before the latch-speed phase completes the final portion of travel. Dormakaba’s current surface-closer documentation likewise provides different templates for regular arm, top jamb, parallel arm, and track applications, rather than one universal mounting position.
The practical lesson is: choose the closer and mounting geometry for the door first, then use that exact manufacturer’s template, and adjust the hydraulic controls only after the mechanical installation is correct. Rainbow Locksmith NY has a dedicated door closer installation service for apartment, commercial, lobby, storefront, and other NYC doors, along with broader door closer services covering repair, replacement, and adjustment.
First choose a closer sized for the door and determine whether the manufacturer calls for regular-arm, top-jamb, or parallel-arm mounting. Inspect the hinges, latch, door and frame before using the exact installation template to mark and drill the mounting holes. Secure the closer body and arm with fasteners appropriate for the door construction, set the arm length and required preload according to the manufacturer’s instructions, and then adjust spring power and hydraulic controls. Set the main closing speed first, then the latch speed and backcheck. Finally, test the door from full, partial and small openings to confirm it closes smoothly and latches without slamming.
What type of door closer are you installing?
The term “door closer” covers several different systems. Before choosing an installation method, identify the closer category.
Surface-mounted overhead closer
This is the familiar hydraulic closer mounted visibly near the top of the door or frame, and the main focus of this guide because these closers commonly support several installation geometries. Current dormakaba closer families provide separate installation templates for regular arm, top jamb, parallel arm, and in some models track mounting. Surface-mounted closers are widely used on apartment entrances, office doors, commercial entrances, corridors, service doors, lobby doors, interior fire doors, and institutional doors.
Concealed overhead closer
A concealed closer is installed inside the door or frame rather than sitting visibly on its face. Installation is substantially different because the door and frame need the correct internal preparation. This should not be approached using a surface-closer template.
Floor closer or floor spring
A floor closer sits beneath the door rather than above it. These systems are particularly common with heavy glass and frameless commercial entrances – dormakaba’s BTS-series products, for example, are dedicated floor-concealed closer systems with separate templates for aluminum, wood, steel, center-hung, offset, and rated applications. Floor-closer installation involves pivots, floor preparation, door geometry, and often glass-door hardware, so it should not be confused with mounting an ordinary overhead closer. For storefront glass doors, Rainbow Locksmith NY has a separate storefront glass door closer repair service covering surface closers, concealed closers, floor springs, pivots, and alignment problems.
The three main surface-closer mounting positions
One of the biggest installation decisions is deciding where the closer body and arm will sit. For common surface closers, the three primary arrangements are regular arm, top jamb, and parallel arm. Dormakaba currently publishes distinct templates for all three configurations across multiple closer families.
Regular arm mount: pull side
With a regular-arm installation, the closer body is typically mounted on the pull side of the door, while the arm shoe attaches to the frame. This arrangement offers straightforward geometry and is commonly used where exposed arm hardware on the pull side is acceptable. Choose regular arm when the pull side has adequate mounting space, the door’s top rail can support the closer, the frame can support the arm shoe, an exposed projecting arm is acceptable, and the manufacturer template permits the required opening angle. Do not choose it simply because it looks easiest to install – the door and frame construction still need adequate reinforcement for the supplied fasteners.
Top jamb mount: push side
In a top-jamb installation, the closer body is mounted on the frame head on the push side, with the arm connected to the door. Top jamb can be useful when the door itself has a narrow top rail that does not provide enough room for the closer body. However, the frame needs enough space and structural support for the closer. Measure the frame rather than assuming the body will fit.
Parallel arm mount: push side
Parallel-arm installation also uses the push side, but the arm folds so it lies more nearly parallel with the door when the door is closed. This configuration is common where projecting arm hardware is undesirable or where the door is subject to heavier public use. Because the geometry differs from regular arm, do not use the regular-arm drilling pattern and simply reposition the arm afterward. Use the dedicated parallel-arm template supplied for the specific closer.
Each mounting geometry changes the closer-body position, arm-shoe position, arm geometry, mechanical leverage, maximum opening, required brackets, required plates, and hole locations. Dormakaba’s 7400, 8600, 8900, and QDC-series documentation all provide distinct mounting templates because these dimensions are not interchangeable. Determine the mounting method first, then use that template only.
Choose the correct closer before installing it
A professional installation begins with closer selection rather than adjustment. LCN recommends considering usage frequency, door application, durability, required functions, spring size, materials, fasteners, environmental conditions, accessibility, and fire and life-safety requirements when specifying a closer.
Door width matters
A wider door creates greater leverage against the closer, so manufacturers size spring power around door dimensions and application. Some current commercial closers are adjustable across a broad spring range – dormakaba’s QDC100, for example, is adjustable from spring size 1 through 6. Do not assume that setting every adjustable closer to maximum power is safer: higher spring power also makes the door harder to open. LCN confirms that increasing spring power increases closing force but also increases opening force.
Door weight matters
A heavy solid-core, steel, or glass door may need a stronger or more durable closer than a lightweight interior door. The closer also has to control the moving mass safely.
Traffic level matters
A door opened a few times per day has a very different duty cycle from a busy office lobby, school, medical building, or storefront. LCN recommends heavier-duty closers for high-frequency, exterior, school, and public-building applications. Do not install a light residential closer on a door that will see commercial traffic and expect adjustment screws to compensate for undersized hardware.
Exterior conditions matter
Wind, stack effect, HVAC pressure, and temperature can substantially change how an entrance behaves. LCN notes that hydraulic fluid viscosity changes with temperature unless an all-weather fluid is used; colder temperatures can slow closing while heat can increase closing speed. A closer should therefore be selected for the environment rather than adjusted only for one unusually calm day.
Inspect the door before installing the closer
A closer cannot repair a door that is mechanically unhealthy. Before opening the closer package, inspect the entire swing door.
Check the hinges or pivots
Open the door partly and observe whether it drops, rubs, shifts, or has excessive play. Loose hinges or worn pivots change the door’s position relative to the frame – a closer installed on a sagging door will spend its life fighting another hardware problem. Check for loose hinge screws, worn hinge knuckles, missing fasteners, door sag, binding, and damaged pivots. HPD’s self-closing-door guidance likewise instructs owners and tenants to check whether hinges are intact, loose, or missing when diagnosing a self-closing door.
Check the latch
Close the door manually before installing the closer. Does the latch engage naturally? If you already have to push the door hard into the frame before the latch catches, increasing closer power is not necessarily the correct repair. Investigate the strike position, door sag, weatherstripping, frame movement, and latch condition. The closer should supply the final controlled closing force – not cover up severe misalignment.
Check the door stop
Backcheck is not designed to replace a physical door stop. LCN specifically states that backcheck cushions the opening swing but does not replace an auxiliary stop. If the wall, frame, closer arm, hinges, or glass are being used as the physical stop, correct that before relying on the closer’s hydraulic backcheck.
Check door and frame reinforcement
Door closers create repeated mechanical loads at their mounting points. LCN recommends using the proper manufacturer-specified fasteners based on door and frame material, and notes that some wood-door constructions require through-bolts unless appropriate internal blocking is provided. Do not assume the screws in the box can be installed into any material in the same way.
Determine the required opening angle
Before placing the template, determine how far the door needs to open. Closer templates often change mounting dimensions based on desired degree of opening. The available opening can also be limited by the wall, a door stop, adjacent hardware, frame projection, a parallel-arm bracket, the building layout, or the closer model. Use the opening-angle information on the exact installation template. Do not guess and then discover that the newly installed closer prevents the door from opening far enough for normal use.
Use the manufacturer’s template – not measurements from another closer
A door closer template is not just a convenience. It establishes the geometry between the hinge or pivot centerline, closer body, pinion shaft, main arm, forearm, and arm shoe or parallel bracket. Dormakaba maintains separate templates for each mounting style across its closer families, and LCN likewise provides model-specific installation resources, including dedicated installation guidance for the 4040XP and 4011 closer families. Do not copy hole locations from an old closer simply because the replacement body is approximately the same size.
Tools for a typical surface-closer installation
A typical installation may require the manufacturer installation template, tape measure, pencil, level, drill and correct bits, a tap for machine screws where specified, screwdrivers, Allen keys, a wrench, a ladder or stable work platform, appropriate manufacturer fasteners, and through-bolts or reinforcement hardware where required. The door material determines the drilling and fastening method – wood, aluminum, hollow metal, and reinforced steel doors should not automatically receive the same fasteners.
Professional installation workflow
Rather than treating door closer installation as a generic numbered kit assembly, think of the installation in four phases: layout, mechanical mounting, arm geometry, hydraulic adjustment. Do not move to the next phase until the previous one is correct.
Phase 1: lay out the closer accurately
Identify whether the door is left-hand or right-hand according to the closer manufacturer’s instructions, and confirm whether you are installing regular arm, top jamb, or parallel arm – the template orientation depends on that decision. The hinge or pivot centerline is a critical reference: tape the manufacturer’s template securely to the correct door or frame surface and make sure it is not rotated or shifted. Recheck the door side, hinge side, opening angle, mount type, and template orientation. Measure twice before marking holes.
Before drilling, hold the closer body and arm near the proposed location and make sure it will not interfere with door trim, glass, the existing lock, alarm contacts, weatherstripping, frame projection, the ceiling, or other door hardware. A technically correct template position may still require a manufacturer-approved drop plate or mounting plate when the door rail is too narrow – dormakaba’s current QDC and 7400 documentation includes optional drop and back plates for exactly these mounting constraints.
Phase 2: drill and mount the hardware
Follow the manufacturer’s specified drilling method for the door material, and do not oversize holes because the closer is heavy – proper fastening depends on correct thread engagement and reinforcement. Mount the closer body squarely: it needs to sit flat against its mounting surface, and you should not use the screws to twist a closer into alignment over an uneven surface. Tighten the mounting fasteners evenly, and before attaching the arm confirm the body is level where required, the fasteners are seated properly, the closer does not rock, the door skin is not crushing, and any mounting plate is stable.
Mount the arm shoe or parallel-arm bracket in the exact template location. Its position affects the arm’s preload and mechanical leverage. Moving the bracket because the arm “almost reaches” can change how the closer operates through the entire swing. If the arm does not fit after using the correct template, recheck the installation rather than relocating the bracket casually.
Phase 3: get the arm geometry right
This is one of the biggest differences between a professional closer installation and a closer that simply happens to shut the door. The arm’s geometry determines how the closer transfers spring force to the door. Install the main arm on the correct pinion position, following the manufacturer’s arm-positioning instructions exactly. Set the forearm length according to the template – incorrect forearm length can create weak latching, excessive closing force, a door that will not open fully, poor backcheck behavior, an incorrect arm angle, and premature hardware wear. Many closer arm installations also require spring preload as the arms are connected; that preload gives the closer the correct mechanical relationship at the closed position. If you ignore it and simply connect the arm wherever it naturally rests, the closer may not develop adequate closing force near the latch.
Phase 4: adjust the closer correctly
Once the hardware is mounted properly, hydraulic adjustment can begin – do not start turning valves randomly. On LCN and Falcon hydraulic closers, Allegion identifies three common regulating controls plus spring adjustment: backcheck, main closing speed, latch speed, and spring power. Closers with delayed action have an additional delayed-action valve. Different brands can label valves differently, so use the instructions for the exact closer.
Spring power is not a speed adjustment
This is one of the most important distinctions in door-closer setup. The spring supplies closing force; the hydraulic valves control how quickly the door moves through different parts of the cycle. LCN states that increasing spring power creates more closing force but also makes the door harder to open. If the door reaches the frame slowly but cannot latch, do not automatically open the latch-speed valve until the door slams – check latch alignment, weatherstripping, door pressure, spring power, and closer size. Allegion specifically warns that opening the latch-speed valve increases speed but does not increase the spring’s closing force; if more force is genuinely required, spring power is the relevant adjustment.
Sweep or main closing speed
The main-speed adjustment controls most of the closing cycle – on LCN closers, Allegion describes it as the main closing region down to roughly the last 15 degrees before the latch phase. The door should move smoothly through this zone: it should not race toward users, stop halfway, creep excessively, or change speed unpredictably. Make small adjustments and test the complete cycle after each change.
Latch speed
The latch-speed control handles the final portion of closing – approximately the last 15 degrees of door movement. This final phase needs enough controlled motion for the latch to engage without making the door slam. If the door reaches the frame gently but does not latch, first identify why: insufficient spring force, a misaligned strike, heavy seal pressure, door sag, or a latch problem. Do not use excessive latch speed to compensate for an alignment problem.
Backcheck
Backcheck controls resistance during the opening cycle, helping slow a door that is thrown or caught by wind. LCN emphasizes that backcheck is designed to slow the opening door, not serve as the physical stop. Too little backcheck can allow the door to hit the stop violently; too much can make the entrance unnecessarily difficult to open near the end of its travel. Adjust it according to the door environment.
Delayed action
Some closers have delayed action, which slows part of the initial closing movement after the door has been opened wide. LCN states that delayed-action closers have an additional fourth regulating valve and that the delay operates through a defined opening zone before normal closing speed takes over. Delayed action can be useful where people need more time to move through a doorway, but it should only be configured on a closer designed for that function.
Adjustment screws are not meant to be removed. Allegion warns that LCN regulating valves have limited adjustment – opening them too far can damage seals and cause hydraulic leakage, and it specifically states that its manual closer valves should not be opened more than three full turns from the shut-off position. That numerical limit is LCN-specific, not a universal rule for every brand. The universal principle: never keep backing an adjustment valve out because the door still does not behave correctly. At some point you are no longer adjusting the door – you are risking damage to the closer.
How fast should a door closer close?
There is no useful professional answer such as “make it close in exactly three seconds.” The correct timing depends partly on accessibility requirements and door function. LCN recommends a normal closing time of approximately 5 to 7 seconds from 90 degrees for many applications, divided between main and latch speed. For doors subject to ADA accessibility requirements, the U.S. Access Board states that a closer must take at least 5 seconds to move from 90 degrees open to 12 degrees from the latch. That requirement concerns closing speed – not total time until the latch clicks. Do not speed up an accessible door simply because someone thinks it “feels slow.”
Door opening force and accessibility
Closer spring power directly affects how difficult the door is to open. The ADA Accessibility Standards specify a maximum opening force of 5 pounds for accessible interior hinged doors other than fire doors. Exterior hinged doors are not given that same 5-pound maximum in the federal standard, and fire doors are subject to the minimum force allowed by the appropriate authority. This nuance matters: do not state that “all ADA doors must open with five pounds of force” – that is not what the federal standard says. A professional closer adjustment balances reliable closing, positive latching, reasonable opening force, required accessibility, and fire-door requirements where applicable.
NYC apartment doors: closing and latching are not optional
Door closer installation has particular importance in NYC multiple dwellings. HPD states that apartment doors and hallway doors covered by the requirement must swing closed and latch on their own. HPD inspectors look for conditions that prevent self-closing, sealing, or latching, and a defect preventing proper self-closing operation can result in a Class C immediately hazardous violation. The city’s 2025 self-closing-door guidance also tells property owners to repair defective closers, hinges, latches, and frames promptly.
For apartment doors, the final installation test should therefore be much more than “the arm moves.” Open the door fully and let go. Confirm that:
- The door swings fully shut.
- The door closes completely.
- The latch engages.
- No floor mat or object interferes.
- The hinges remain stable.
- The closer arm operates without binding.
- The door does not need to be pulled closed manually.
Rainbow Locksmith NY provides dedicated door closer installation in NYC for apartment and building doors where reliable self-closing operation is required.
Fire doors need special attention
A fire door closer has a life-safety function: the door must be capable of returning to the closed and latched position when required. LCN notes that fire doors equipped with closers must be adjusted so they latch reliably when they close. Do not install an ordinary mechanical hold-open arm on a fire door just because users prefer the door to remain open. Fire-door hold-open systems can require approved devices integrated with fire-detection or alarm functions so the door releases and closes when required – LCN specifically describes electronic hold-open options used in conjunction with fire-detection systems. Rainbow Locksmith NY has a separate fire-rated door closer installation service for these installations.
Professional tip: adjust the door, not just the closer
If a new closer cannot make the door behave correctly, do not immediately assume the closer needs more power. Test the door itself. The underlying questions are simple: does the door move freely, does it bind, does it sag, does the latch line up, does air pressure resist closing? The closer should control the door. It should not overpower a mechanical defect.
Common closer problems after installation
Why a door slams after closer installation
A slamming door can result from the main-speed setting being too fast, the latch-speed setting being too fast, valve over-adjustment, hydraulic failure, closer damage, incorrect closer size, or an installation geometry problem. If adjustment makes little difference or hydraulic fluid is visible around the closer body, the unit may be failing rather than merely misadjusted. Rainbow Locksmith NY’s door closer repair service covers slamming, failure to latch, arm problems, leaks, and related closer issues.
Why the door closes but does not latch
Possible causes include spring power too low, strike misalignment, a latch problem, door sag, weather seal pressure, HVAC pressure, incorrect arm preload, or an undersized closer. Do not simply increase latch speed until the door hits the frame violently – the latch valve changes speed, while spring adjustment changes available closing force.
Why the door is too hard to open
If the closer is mechanically healthy but users struggle to open the door, possible causes include excessive spring power, incorrect closer size, incorrect mounting geometry, too much backcheck near the open position, binding hinges, door and frame interference, or a pressure differential. Remember that decreasing spring power may reduce opening force, but it also reduces available closing force. The adjustment needs to preserve reliable closing and latching.
Why the door stops before fully closing
A door that stops several inches from the frame may have a problem outside the closer. Inspect the hinges, frame, floor, weatherstripping, door sweep, latch, arm geometry, and objects in the path. If the closer is trying to move a binding door, hydraulic adjustment alone will not solve the problem.
Why the closer arm keeps coming loose
A repeatedly loose arm can indicate a loose arm screw, a damaged pinion connection, incorrect arm installation, missing hardware, excessive door abuse, lack of a proper door stop, incorrect preload, or a bent arm. Do not keep tightening a damaged joint indefinitely – inspect the connection and replace worn components where necessary.
Why the closer body pulls away from the door
This is usually a mounting issue rather than a hydraulic adjustment problem: incorrect fasteners, a door skin too thin, missing reinforcement, stripped mounting holes, heavy abusive use, the wrong mounting plate, or an incorrect installation. LCN specifically emphasizes using appropriate manufacturer fasteners for the actual door and frame material. If the mounting surface cannot support the closer, more spring adjustment will only add stress.
When a drop plate is necessary
A drop or mounting plate is used when the closer cannot be mounted directly in the ideal template location because of insufficient rail height or other geometry. Dormakaba specifically offers drop-plate and backplate options on several current closer series for these conditions. Use the plate designed for that closer family. Do not fabricate an arbitrary spacer plate unless the complete installation has been engineered appropriately.
Surface closer vs. concealed closer vs. floor closer
Surface-mounted closers are easier to inspect, adjust, and replace because the hardware remains accessible. Concealed closers provide a cleaner appearance but require specific door or frame preparation – do not cut a standard door or frame for a concealed closer simply because the hardware looks better. A floor closer can be ideal for certain heavy glass or architectural doors where overhead hardware is undesirable, but installation is much more involved: dormakaba’s current BTS floor-closer families use dedicated templates for different pivot, door, frame, and rated configurations. For a typical wood or hollow-metal swing door, a surface closer is often much easier to service. For frameless heavy glass, the floor closer may already be integral to the door system.
Repair or replace an existing closer?
Not every bad closer needs replacement. Adjustment or repair may be reasonable when the closer is not leaking, the arm is intact, the mounting remains secure, the speed is simply misadjusted, the door has recently shifted, or fasteners have loosened. Replacement becomes more appropriate when hydraulic fluid is leaking, the closer body is cracked, the internal mechanism has failed, adjustment valves no longer control movement, the closer is badly undersized, mounting damage is extensive, or the unit is no longer appropriate for the application. Rainbow Locksmith NY has a separate door closer replacement service for units that have reached the point where repair is no longer practical.
Common swing door closer installation mistakes
Closer installation errors often appear to be adjustment problems later. Avoid:
- Choosing a closer by price alone
- Ignoring door width and weight
- Using the wrong mounting configuration
- Using a regular-arm template for a parallel mount
- Copying holes from an unrelated old closer
- Ignoring hinge or pivot problems
- Installing into unreinforced door skin
- Using unsuitable fasteners
- Moving the arm bracket because the arm “almost fits”
- Ignoring manufacturer preload instructions
- Setting spring power to maximum automatically
- Using latch speed as a substitute for closing force
- Making large hydraulic adjustments
- Backing hydraulic valves out too far
- Using backcheck as the physical door stop
- Ignoring accessibility requirements
- Using an inappropriate hold-open device on a fire door
- Failing to test full self-closing and latching operation
A professionally installed closer should control the door quietly without making its presence obvious.
The professional final-test sequence
Do not test the closer once and leave. A good commissioning process checks the door through several different conditions:
- Test from full open. Open the door to its normal maximum position, release it, and watch the complete closing cycle. The door should transition smoothly from opening control to sweep speed and finally into the latch phase.
- Test from half open. Open the door approximately halfway and release it. It should still close and latch.
- Test from a small opening. Open the door only a short distance and release it. For doors required to self-close, make sure the closer still has enough force to complete the closing cycle.
- Test the latch. The door should not stop against the frame without engaging the latch – HPD specifically treats proper latching as part of self-closing-door performance in NYC apartment and hallway doors.
- Test opening force. Where accessibility requirements apply, check the door opening force rather than assuming it is compliant because the closer is adjustable.
- Test closing time. Where ADA closing-speed requirements apply, the door should take at least 5 seconds to travel from 90 degrees open to 12 degrees from the latch.
- Repeat the cycle. Open and close the door multiple times – the performance should remain consistent. A closer that behaves correctly once but unpredictably afterward is not ready to be considered finished.
When professional installation is the better choice
A basic surface closer on a sound wood door can be manageable for someone comfortable with precise layout, drilling, and hardware adjustment. Professional installation is more appropriate when:
- The door is fire-rated
- The door is part of an accessible route
- Hollow-metal preparation is uncertain
- The door lacks closer reinforcement
- Existing mounting holes are damaged
- A commercial entrance receives heavy traffic
- The door is unusually wide or heavy
- Glass storefront hardware is involved
- A floor closer or concealed closer is involved
- The door cannot latch reliably
- The building has an HPD self-closing violation
- The closer must interface with hold-open or fire-alarm equipment
- Several door components are already misaligned
Rainbow Locksmith NY offers door closer installation, door closer repair, door closer replacement, and fire-rated door closer installation throughout New York City.
Frequently asked questions
What are the three main ways to install a surface door closer?
The three common configurations are regular arm, top jamb, and parallel arm. Regular arm is typically a pull-side installation, while top jamb and parallel arm are commonly push-side configurations.
Which side does a regular-arm door closer go on?
A regular-arm surface closer is typically mounted on the pull side of the door. The closer body mounts to the door while the arm shoe attaches to the frame in common configurations.
What is a parallel-arm door closer?
A parallel-arm closer uses a push-side mounting configuration in which the arm folds more nearly parallel to the door when closed. Manufacturers provide dedicated parallel-arm templates because the body and bracket locations differ from regular-arm installation.
When should I use top-jamb mounting?
Top-jamb mounting can be useful when the door’s top rail does not provide enough room for the closer body. In this configuration, the closer body is commonly mounted on the push-side frame head.
How do I know what size door closer I need?
Use the closer manufacturer’s sizing information and consider door width, weight, interior versus exterior use, traffic, pressure, mounting configuration, and accessibility requirements. Many commercial closers offer adjustable spring power; dormakaba’s QDC100, for example, adjusts from sizes 1 through 6.
What does the sweep-speed adjustment do?
The main or sweep-speed valve controls most of the door’s closing cycle before the final latch-speed zone – roughly down to the last 15 degrees.
What does latch speed control?
Latch speed controls the final part of door closing. It should allow enough controlled motion for the latch to engage without causing the door to slam.
What does backcheck do?
Backcheck provides hydraulic resistance near the opening end of the swing so a door that is thrown or caught by wind does not move as violently. It is not intended to replace a mechanical door stop.
Does increasing latch speed give the door more closing force?
No. Opening the latch-speed valve increases the speed of the final closing phase, while spring-power adjustment changes the actual closing force.
Why does my door closer slam?
Possible causes include excessive speed adjustment, hydraulic failure, incorrect closer size, damaged valves, or improper installation. If adjustment no longer controls the door or the closer is leaking, service or replacement may be required.
How fast should a door closer close?
LCN recommends approximately 5-7 seconds from 90 degrees for many normal applications. For doors covered by ADA closer-speed requirements, movement from 90 degrees to 12 degrees from the latch must take at least 5 seconds.
Does ADA require every door to open with five pounds of force?
No. The federal accessibility standard applies the 5-pound maximum to accessible interior hinged doors other than fire doors. Exterior hinged doors and fire doors are treated differently in the federal standard.
Can I turn a door closer adjustment screw all the way out?
Do not do that. Hydraulic regulating valves have adjustment limits and can leak if backed out too far. Allegion specifically warns against opening LCN manual-closer valves beyond their allowable range.
Why is my NYC apartment door closer important?
NYC HPD requires applicable apartment and hallway doors to close and latch automatically. A defect that prevents proper self-closing or latching can result in an immediately hazardous violation.
Can I put a hold-open arm on a fire door?
Not simply because you want the door to remain open. Fire-door hold-open arrangements can require approved automatic-release systems tied to fire detection or alarms so the door closes when required.
Should I replace a leaking door closer?
A visible hydraulic leak can indicate seal or internal closer failure. If the unit can no longer maintain controlled movement, replacement is generally more appropriate than trying to compensate with adjustment.
